Tempat asal:
Cina
Nama merek:
Hengyang
Sertifikasi:
ISO9001
Nomor model:
HC-246
|
|
|
Listrik-Pemanas (Pemanasan tidak langsung) Sumber Rotary Drum Dryer Detail Teknis
| Jenis | Spek | Dia dari Roll | Panjang gulungan | Gradien | Kecepatan (rpm) | Berat (t) | Tenaga Motor (kw) | Daya Pemanasan (KW) |
| HY600 | φ 0,6× 8 | φ 600 | 8m | 3-5 | 8 | 5.1 | 4/6p | 45 |
| HY800 | φ 0,8 × 10 | φ 800 | 10 m | 3-5 | 7.2 | 6.9 | 4/6p | 60 |
| HY1000 | φ 1,0× 10 | φ 1000 | 10 m | 3-5 | 6.73 | 7.5 | 5,5/6p | 90 |
| HY1200 | φ 1,2× 12 | φ 1200 | 12m | 3-5 | 5.8 | 13.1 | 11/6p | 120 |
| HY1500 | φ 1,5× 12 | φ 1500 | 12m | 3-5 | 4.8 | 22.3 | 15/6p | 150 |
| HY2200 | φ 2,2× 14 | φ 2200 | 14m | 3-5 | 3.2 | 52.8 | 30 | 200 |
| HY2400 | φ 2,4× 18 | φ 2400 | 18m | 3-5 | 3 | 73.3 | 37 | 300 |
| HY2800 | φ 2,8× 24 | φ 2800 | 24 m | 3-5 | 2.59 | 97 | 75 | 400 |
Kirim pertanyaan Anda langsung ke kami
